Industry and FPV crossing drones, new weapons for flight enthusiasts to experience extreme flight,3KG load, flight speed of 180Km/h, endurance of 29 minutes.
Product Display：
Adopting high-strength aviation grade 3K carbon fiber brackets can effectively protect internal components and prevent impact damage.
Starlight level lens:
even on nights without starlight, can capture the scene clearly, ensuring the normal flight of the aircraft without being limited by light, and flying easily day and night；Resolution：1200TVL,Horizontal viewing angle 160 °，Video format：NTSC&PAL,Low illumination：0.001LUX.
Racing specific flight control：
The latest F405 V3 flight controller，to provide high-performance flying experience for pilots, it can be perfectly applied to FPV competitions, stunt flying, and aerial photography. At the same time, pilots can freely adjust parameters according to their own needs.
Super strong transmitting antenna：
Super strong launch distance, real-time monitoring of flight status and parameters, video transmission distance of 7-10 kilometers, even if flying through, the image is clear and smooth.
aviation goggles：
FPV aviation goggles adopting high-definition and low latency digital image transmission technology, presenting 720P/fps high-definition and low latency image transmission images for pilots, bidding farewell to low resolution analog image transmission, and making the vision of racing flight clearer from now on。
Product Parameters：
| project | parameter | project | parameter |
| Body dimensions | 310*375*130mm | Diagonal wheelbase | 427mm |
| bare weight | 985g | Spiral Palm Size | 10Inch |
| Structural thickness | roof panel2mm,
baseplate：2mm Thickness of plywood：3mm |
Maximum flight speed | 180km/h |
| Maximum flight distance | 7-10km/h | Ceiling | 3000m |
| Maximum Load Capacity | 3kg | 5000mAh Empty flight time | 29minute |
| 5000mAh load capacity3kg
flight time |
7minute | 10000mAh load capacity3kg
flight time |
14minute |
| Working environment temperature | -10 ℃ -40 ℃ | flight control | F4betaflight |
| Motor | 3115kv900 | MCU | F405 |
| OSD | support | ELRS | 915MHz |
| Image transmission | 5.8GHz 2.5W | Power adjustment | CFLY 60A6S |
| Lens Resolution | 1200TLV | Remote control battery
capacity |
5000mAh |
| Voltage | 22.2V | Maximum charging power | 80W |
| Charging time | 1.5h | Usage time | 5H |
| battery voltage | 6-8.4V | Charging time | 4H |
| FPV aviation goggles:
screen size |
4.3Inch | resolution | 480*272pix |
| perspective | 120° | lens | 93% |
| Brightness | 500cd/m² | Interface | USB |
| Weight | 300g | Built-in battery | 3.7V2200mah |
| Size | 156*150*95mm | ||
